before/after hpi rush wide pede conversion

B

brick64vxl

New Member
BEFORE
http://i249.photobucket.com/albums/gg218/brick64vxl/DSCN2666.jpg

http://i249.photobucket.com/albums/gg218/brick64vxl/DSCN2665.jpg

http://i249.photobucket.com/albums/gg218/brick64vxl/DSCN2664.jpg

http://i249.photobucket.com/albums/gg218/brick64vxl/011.jpg

AFTER
http://i249.photobucket.com/albums/gg218/brick64vxl/010.jpg

http://i249.photobucket.com/albums/gg218/brick64vxl/009.jpg

http://i249.photobucket.com/albums/gg218/brick64vxl/008.jpg

WIDTH INCREASED BY 3/4"

APPROX COST $50
HPI RUSH A-ARMS (A459) $9
96MM TRAXXAS T-MAXX TURN BUCKLES(TRA2338) $6
SET OF FRONT VXL BLACK CHROME WHEELS AND TIRES(F3669A) $31
TRAXXAS SUSPENSION PINS(TRA2637) $3

Dougie

Dougie

Well-Known Member
Did you lable those backwards or did you want to make the truck narrower? I only ask because in your before pic it shows the width just over 14 inches, and after I think it was just over 13, that is why I was thinking they might be labeled backwards

B

brick64vxl

New Member
oops i must have gotten the pics mixed up while i was posting....the truck was 13-1/4" and now is 14"

and no the parts are not a direct bolt on i made some spacers and used some washers...the a-arms also need drilled out with an 1/8" drill

the back side of the a-arms also need slightly sanded down so you can get the e-clip on

you'll have to use your imagination a little and be creative to make this work but it is fun and alot of guys have done this before me

S

Savage03

bad trader
Ah I did the rear pede arms all around on mine and front rims all around. Think my build is on page 2 now. Nice rig tho :tmb
